Detailed Description
2.3 Configurable gear adaptation
Basic logic functions: Spindles (S1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
41
The parameter sets of gear steps 1 to 5 can be configured with the following machine data:
First Gear Step Data Set Speed min./max.
MD35110 $MA_GEAR_STEP_MAX_VELO[n] max. of GSW
MD35120 $MA_GEAR_STEP_MIN_VELO[n] Min. of GSW
MD35130 $MA_GEAR_STEP_MAX_VELO_LIMIT[n] Max. gear step
MD35140 $MA_GEAR_STEP_MIN_VELO_LIMIT[n] min of gear step
Acceleration in:
MD35200 $MA_GEAR_STEP_SPEEDCTRL_ACCEL[n] Speed control mode:
MD35210 $MA_GEAR_STEP_POSCTRL_ACCEL[n] Position controller mode
MD35012 $MA_GEAR_STEP_CHANGE_POSITION[n] Gear step change position
Second Gear Step Dat Set
The automatic gear step change M40 will be extended by a second configurable gear step
data set. The number of gear steps 1 to 5 used by this second data set is determined with
the machine data:
MD35092 $MA_NUM_GEAR_STEPS2
The second data set of gear step set is deactivated if zero is entered in this machine data, as
in the standard case. With an active M40 the selection of the gear step is then carried out
through the first data set, as before.
Note
The number of gear steps in the second data set can vary from the first. If no appropriate
gear step is found for a programmed speed for M40, then - as before - no gear step change
is carried out. For further information on a typical program execution for rigid tapping
G331/G332 see:
Literature:
/PG/ Programming Manual Basic/ Distance Commands Programming
Gear steps 1 to 5 are configurable for an automatic gear step change with the following:
Second Gear Step Data Set Speed min/max:
MD35112 $MA_GEAR_STEP_MAX_VELO2[n] max of GSW
MD35122 $MA_GEAR_STEP_MIN_VELO2[n] min of GSW
Acceleration in:
MD35212 $MA_GEAR_STEP_POSCTRL_ACCEL2[n] Position controller mode
