Detailed Description
2.3 Tool cutting edge
Basic logic functions: Tool Offset (W1)
36 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
The following tool parameters are available for the relevant tool types:
Tool parameter Significance Note
1 Tool type
2 Cutting edge position for turning tools or for milling/grinding tools
with 2D TRC contour tool
Geometry - tool length compensation
3 Length 1
4 Length 2
5 Length 3
Geometry - tool radius compensation
6 Radius 1/Length 1 for 3D face milling
7 Length 2 for 3D face milling
8 Radius 1 for 3D face milling
9 Radius 2 for 3D face milling
10 Angle 1 / minimum threshold angle for 3D face milling
with 2D TRC contour tool
11 Angle 2 / minimum threshold angle for 3D face milling
with 2D TRC contour tool
Wear - tool length compensation
12 Length 1
13 Length 2
14 Length 3
Wear - tool radius compensation
15 Radius 1/Length 1 for 3D face milling
16 Length 2 for 3D face milling
17 Radius 1 for 3D face milling
18 Radius 2 for 3D face milling
19 Angle 1 /
minimum limit angle
for 3D face milling
with 2D TRC contour tool.
20 Angle 2 /
maximum limit angle
for 3D face milling
with 2D TRC contour tool.
Tool base dimension/adapter dimension - tool length compensation
21 Basic length 1
22 Basic length 2
23 Basic length 3
Technology
24 Undercut angle only for turning tools
25 Reserved
*
*
"Reserved" means that this tool parameter on the 840D/810D is not used and is reserved for
expansions.
