Detailed description
2.3 Continuous -path mode
Basic logic functions: Continuouspath Mode, Exact Stop, LookAhead (B1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
43
Example of programming with index:
MD32300 $MA_MAX_AX_ACCEL[3, AX1]=1
R1=MD20602 $MC_CURV_EFECT_ON_PATH_ACCEL[4]
Notice
Writing the machine data without an index places the same value in all field elements of the
machine data in question.
Reading the machine data without an index always supplies the value of the field with index
0.
These configurations may occur:
1. Write from the part program MD32300 $MA_MAX_AX_ACCEL[AX1]=1 sets all five field
elements to value 1 (unit of measurement metric or inch depending on axis type and
reference system).
2. Read in archive files from software versions earlier than SW 7.2.
Activate parameter sets for dynamic response
By programming G codes, the machine data affecting dynamics are activated and assigned
as follows:
Active parameter set
G CODE of group 59 technology:
Index 0: Value for:
DYNNORM
Index 1: Value for:
DYNPOS
Index 2: Value for:
DYNROUGH
Index 3: Value for:
DYNSEMIFIN
Index 4: Value for:
DYNFINISH
Note
We recommend suppressingG codes that are not usedwith the machine data:
MD10712 $MN_ NC_USER_CODE_CONF_NAME_TAB[n] (list of reconfigured NC codes).
This will prevent these G codes from being programmed accidentally and activating
unconfigured machine data.
