Detailed Description
2.1 Various interface signals and functions (A2)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
25
DB19
DBX26.1 OK (job list selection from PLC, status)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Transfer correctly completed
Signal state 0 or
edge change 1 → 0
Transfer completed with error
Corresponding to .... Valid for HMI Advanced
DB19
DBX26.2 Error (job list selection from PLC, status) (previously bit 0)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Transfer completed with error
Signal state 0 or
edge change 1 → 0
Transfer correctly completed
Corresponding to .... Valid for HMI Advanced
DB19
DBX26.3 Active (job list selection from PLC, status)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Job in progress
Signal state 0 or
edge change 1 → 0
No task in progress
Corresponding to .... Valid for HMI Advanced
DB19
DBX26.5 Unload (job list selection from PLC, status)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Unload active
Signal state 0 or
edge change 1 → 0
Unloading inactive
Corresponding to .... Valid for HMI Advanced
