Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
Basic logic functions: NC/PLC interface signals (Z1)
82 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DB11, ...
DBX1.1
Machine function REPOS
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Machine function REPOS is activated in JOG mode for the mode group.
Signal state 0 or
edge change
1 → 0
Machine function REPOS is not activated.
Signal irrelevant for
...
JOG mode is not active.
Application
example(s)
When a fault occurs when executing a part program (e.g. tool breakage), the axis is manually
moved away from the fault location in the JOG mode in order to be able to replace the tool.
The axis can then be manually returned to the precise previous position using the REPOS machine
function so that the program can be continued in the automatic mode.
Additional references /BA/ Operations Guide HMI (corresponding to the used software)
DB11, ...
DBX1.2
Machine function REF
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
Machine function REF is activated in the JOG mode for the mode group.
Signal state 0 or
edge change
1 → 0
Machine function REF is not activated.
Signal irrelevant for
...
If JOG mode is not active.
Additional references /FB1/ Functions Manual Basic Functions; Reference Point Travel (R1)
DB11, ...
DBX1.6
Single block type B
Edge evaluation: no Signal(s) updated:
Signal state 1 or
edge change
0 → 1
Bit set and DB11, ...DBX1.7 not set: Response across modes
• All channels are stopped.
• All channels receive a start command.
• Channel KS stops at the end of the block.
• The channels KA receive a STOPATEND.
(comparable with DB21, ... DBX7.2 (NC stop at the block limit).)
• All channels are stopped at a block limit (at some point in time).
(If DB11, ... DBX1.6 and DB11, ... DBX1.7 are set simultaneously, it is impossible to determine
which single block type is required. In this case, the control assumes: No single block across mode
groups).
