Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
85
DB11, ...
DBX5.2
Selected machine function REF
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The machine function REF is selected by HMI within BAG.
Signal status 0 or
edge change
1 → 0
The machine function REF is not selected by HMI.
Additional
References
/FB1/ Functions Manual Basic Functions; Reference Point Travel (R1)
DB11, ...
DBX6.0
Data block
Active mode AUTOMATIC
Signal(s) from the mode group (NCK → PLC)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
AUTOMATIK mode is active.
Signal state 0 or
edge change
1 → 0
AUTOMATIK mode is not active.
DB11, ...
DBX6.1
Active mode MDA
Edge evaluation: Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
MDA mode is active.
Signal state 0 or
edge change
1 → 0
MDA mode is not active.
DB11, ...
DBX6.2
Active JOG mode
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
JOG mode is active.
Signal state 0 or
edge change
1 → 0
JOG mode is not active.
