Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
Basic logic functions: NC/PLC interface signals (Z1)
92 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DB21, ...
DBX7.4
NC STOP axes plus spindles
Edge evaluation: no Signal(s) updated: cyclic
See DB21, ... DBX7.3 (NC STOP).
In addition, the spindles of the channel are stopped.
DB21, ...
DBX7.7
Reset
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The channel is reset. The initial settings are set (e.g. G functions).
The alarms for the channel are cleared if they are not POWER ON alarms.
The reset signal must be issued by the PLC (e.g., using a logic operation with the reset key on the
MCP). The signal is only evaluated by the selected channel.
The program status changes to "Aborted", and the channel status changes to "Channel status
reset".
Signal state 0 or
edge change
1 → 0
No effect.
Corresponds to .... DB11, ... DBX0.7 (mode group reset)
DB21, ... DBX35.7 (channel status reset)
DB21, ...
DBX31.0 - DBX31.2
REPOS mode (REPOSPATHMODE)
Edge evaluation: no Signal(s) updated: cyclic
REPOS mode specified by HMI:
Bit:2 1 0
0 0 0 = 0: no REPOS mode active
0 0 1 = 1: Re-approach to block start RMB
0 1 0 = 2: Re-approach to interruption point RMI
0 1 1 = 3: Re-approach to block end point RME
1 0 0 = 4: Re-approach to nearest path point RMN
Corresponds to .... DB21, ...DBX25.0 - DBX25.2 (REPOS mode (REPOSPATHMODE))
DB31, ... DBX10.0 (REPOSDELAY)
DB21, ...
DBX31.4
REPOS mode change (REPOSMODEEDGE)
Edge evaluation: yes Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The REPOS mode has changed:
DB21, ... DBX31.0 - DBX31.2 (REPOS mode (REPOSPATHMODE))
Signal state 0 or
edge change
1 → 0
REPOS mode has not changed.
Corresponds to .... DB21, ... DBX31.0 - DBX31.2 (REPOS mode (REPOSPATHMODE))
DB21, ... DBX319.0 (REPOSMODEEDGEACKN)
DB21, ...DBX31.0 - DBX31.2 (REPOS mode (REPOSPATHMODE))
