Detailed Description
2.16 Feeds (V1)
Basic logic functions: NC/PLC interface signals (Z1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
141
DB31, ...
DBX4.3
Feed stop/spindle stop (axisspecific)
Application
example(s)
Feed stop:
The traversing motion of the machine axes is not started with "feed stop", if, for example, certain
operating states exist at the machine that do not permit the axes to be moved (e.g. a door is not
closed).
Spindle stop:
In order to change a tool
To enter help functions (M, S, H, T, D and F functions) during setup.
Special cases,
errors, ......
Spindle stop is inactive when G331, G332 are active.
DB31, ...
DBB19
Spindle override
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The spindle override can be defined via the PLC in binary or Gray coding.
The override value determines the percentage of the programmed speed setpoint that is issued to
the spindle.
With binary coding, the override is interpreted in %. 0% to 200% feed changes are possible, in
accordance with the binary value in the byte.
The following permanent assignment applies:
&RGH 6SLQGOHRYHUULGHIDFWRU
ฬ
ฬ
ฬ
ฬ
ฬ
ฬ
Binary values > 200 are limited to 200%.
The machine data:
MD12100 $MN_OVR_FACTOR_LIMIT_BIN (limit for binary-coded override switch)
can be used to additionally limit the maximum spindle override.
