2.4 Closed-loop control
Basic logic functions: Velocities, Setpoint/Actual Value Systems, Closed-Loop Control (G2)
64 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Parameter sets during gear stage change
Interpolation parameter sets during gear stage change:
In the case of spindles, each gear stage is assigned its own parameter set.
The appropriate parameter set is activated, depending on the NC/PLC interface signal:
DB31, ... DBX16.0 - 16.2 (actual gear stage).
DB31, ... DBX16.0 - 16.2 (actual gear stage) Active parameter set
000 1. Gearbox stage 2 (Index=1)
001 1. Gearbox stage 2 (Index=1)
010 2. gear stage 3 (Index=2)
011 3. gear stage 4 (Index=3)
100 4. gear stage 5 (Index=4)
101
110
111
5. gear stage 6 (Index=5)
For more information about gear stages for spindles, see:
References:
/FB1/ Function Manual, Basic Functions; Spindles (S1).
