Data lists
5.1 Machine data
Basic logic functions: Various NC/PLC interface signals and functions (A2)
48 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Number Identifier: $MM_ Description
9007 TABULATOR_SIZE Tabulator length
9008 9008 KEYBOARD_TYPE Keyboard type (0: OP, 1: MFII/QWERTY)
9009 9009 KEYBOARD_STATE Shift behavior of keyboard during booting
9010 SPIND_DISPLAY_RESOLUTION Display resolution for spindle values
9011 9011 DISPLAY_RESOLUTION_INCH Display resolution for INCH_system of units
9012 9012 ACTION_LOG_MODE Set action mode for action log
9013 SYS_CLOCK_SYNC_TIME System clock synchronizing time
9020 9020 TECHNOLOGY Basic configuration for simulation and free
contour programming
9030 EXPONENT_LIMIT Number of places to be displayed without
exponent
9031 EXPONENT_SCIENCE Technical exponent representation in three
steps
9180 USER_CLASS_READ_TCARR Protection level read tool carrier offsets
general
9181 USER_CLASS_WRITE_TCARR Protection level write tool carrier offsets
general
9200 9200 USER_CLASS_READ_TOA Protection level read tool offsets general
9201 9201 USER_CLASS_WRITE_TOA_GEO Protection level write tool geometry
9202 9202 USER_CLASS_WRITE_TOA_WEAR Protection level write tool wear data
9203 9203 USER_CLASS_WRITE_FINE Protection level write fine
9204 USER_CLASS_WRITE_TOA_SC Protection level change total tool offsets
9205 USER_CLASS_WRITE_TOA_EC Protection level change tool setup offsets
9206 USER_CLASS_WRITE_TOA_SUPVIS Protection level change tool-monitoring limit
values
9207 USER_CLASS_WRITE_TOA_ASSDNO Change D No. assigned to a tool edge
9208 USER_CLASS_WRITE_MAG_WGROUP change wear group magazine location/mag.
9209 9209 USER_CLASS_WRITE_TOA_ADAPT Protection level write tool adapter data
9210 9210 USER_CLASS_WRITE_ZOA Protection level write settable zero offset
9211 9211 USER_CLASS_READ_GUD_LUD Protection level read user variables
9212 9212 USER_CLASS_WRITE_GUD_LUD Protection level write user variables
9213 9213 USER_CLASS_OVERSTORE_HIGH Protection level extended overstore
9214 9214 USER_CLASS_WRITE_PRG_CONDIT Protection level program control
9215 9215 USER_CLASS_WRITE_SEA Protection level write setting data
9216 USER_CLASS_READ_PROGRAM Protection level read part program
9217 USER_CLASS_WRITE_PROGRAM Protection level enter part program
9218 9218 USER_CLASS_SELECT_PROGRAM Protection level part program selection
9219 9219 USER_CLASS_TEACH_IN Protection level TEACH IN
9220 9220 USER_CLASS_PRESET Protection level PRESET
9221 9221 USER_CLASS_CLEAR_RPA Protection level delete R parameters
9222 9222 USER_CLASS_WRITE_RPA Protection level write R parameters
9223 USER_CLASS_SET_V24 Protection level for RS232C interface
parameterization
