Detailed description
2.5 Block search
Basic logic functions: Mode group, channel, program operation, reset response (K1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
47
Y
X
100
200
0
300
100 200 300 400
Approach point
(170,30)
Tool
change point
(450,300)
Approach movement
Target block N220
Figure 2-4 Approach movement for search to block end point (target block N220)
Note
"Search to contour" with target block N220 would generate an approach movement to the
tool change point (start point of the target block).
