Detailed description
2.4 Frames
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
77
Axial replacement G58, G59
The translation component of the programmable frame is split into an absolute component
and a component for the total of all additively programmed translations. The absolute
component can be changed using TRANS, CTRANS or by writing the translation components,
in which the additive component is set to zero. G58 changes only the absolute translation
component for the specified axis; the total of additively programmed translations is retained.
G58 X... Y... Z... A... ...
G59 is used for axial overwriting of the additively programmed translations for the specified
axes, which were programmed with ATRANS.
G59 X... Y... Z... A... ...
Example:
TRANS X10 Y10 Z10
ATRANS X5 Y5
; Total translations X15 Y15 Z10
G58 X20
; Total translations X25 Y15 Z10
G59 X10 Y10
; Total translations X30 Y20 Z10
G58 and G59 can be used only if machine data:
MD24000 $MC_FRAME_ADD_COMPONENTS ("Frame components for G58 / G59")
is TRUE, otherwise Alarm "18311 Channel %1 Block %2 Frame: instruction not permissible"
is output.
The function can also only be used in conjunction with a configured fine offset for the
programmable frame. If G58 or G59 is used without a configured fine offset, alarm "18312
channel %1 block %2 frame: Fine offset not configured" is output.
The absolute component of the translation is stored in the rough offset component and the
additive translation component is stored in the fine offset component. To this end, the
programmable frame or the fine offset is expanded.
5RXJKRUDEVROXWH
7UDQVODWLRQ
)LQHRUDGGLWLYH
7UDQVODWLRQ
7UDQVODWLRQ
The fine component is transferred on saving the programmable frame in a local frame
variable (LUD or GUD) and on rewriting.
The table below shows the effect of various program commands on the absolute and
additive translation.
