Detailed description
2.4 Frames
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
131
RESET response of the system frames of TCARR, PAROT, TOROT and TOFRAME
The RESET response of the system frames of TCARR, PAROT, TOROT and TOFRAME
depends on the G-Code RESET setting.
The setting is made with machine data:
MD20110 $MC_RESET_MODE_MASK (definition of initial control settings after RESET/TP-
End)
MD20152 $MC_GCODE_RESET_MODE[ ] (RESET response of G groups)
MD20150 $MC_GCODE_RESET_VALUES (RESET position of G groups)
MD20110 Significance
Bit 0 = 0 TCARR and PAROT system frames are retained as before the RESET.
MD20152 $MC_GCODE_RESET_MODE[51] = 0
MD20150 $MC_GCODE_RESET_VALUES[51] = 1 PAROTOF
MD20150 $MC_GCODE_RESET_VALUES[51] = 2 PAROT
MD20152 $MC_GCODE_RESET_MODE[51] = 1 TCARR and PAROT
system frames are retained
as before the RESET.
MD20152 $MC_GCODE_RESET_MODE[52] = 0
MD20150 $MC_GCODE_RESET_VALUES[52] = 1 TOROTOF
MD20150 $MC_GCODE_RESET_VALUES[52] = 2 TOROT
MD20150 $MC_GCODE_RESET_VALUES[52] = 3 TOFRAME
Bit 0 = 1
MD20152 $MC_GCODE_RESET_MODE[52] = 1 TOROT and TOFRAME
system frames are retained
as before the RESET.
TCARR and PAROT are two independent functions, which describe the same frame. With
PAROTOF, the component of TCARR is not activated on RESET.
