Detailed description
2.1 Key PLC CPU data for 810D, 840D and 840Di
Basic logic functions: PLC Basic program powerline (P3 pl)
14 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
PLC versions
In SW 3.5 and higher on the 840D, version 6 (version code 35.06.03) is installed with PLC
314 and version 3 (version code 35.03.03) with PLC 315-2DP or higher.
These versions are compatible with the corresponding SIMATIC CPU300.
All modules and software packages approved by SIMATIC for these versions and CPUs are
therefore suitable. Modules that can only be installed in subrack 0 are the exception
(modules FM NC and FM 357 are also exceptions).
Version code: XX.YY.ZZ
• XX: SIMATIC CPU PLC version
• YY: Firmware transfer increment
• ZZ: Internal increment
Example
PLC 315-2DP with MLFB 6ES7 315-2AF00-0AB0: 04.02.14
PLC 315-2DP with MLFB 6ES7 315-2AF01-0AB0: 03.10.23
PLC 314: 07.02.12
HMI version display
The PLC module, the PLC operating system version and the module code appear in the last
line of the HMI version display.
Example
PLC module PLC operating system version Module code
S7 PLC_315-2DP system 03.10.23 1200
Module codes
The table below shows the relationship between the module code and the corresponding
PLC module, the suitable PLC operating system and its current software version:
Module code PLC module Suitable PLC operating systems
(corresponding SIMATIC MLFB)
PLC operating
system SW version
0208 PLC 314 6ES7 314–1AE0–0AB0 07.02.12
1008 PLC 3152DP with ASPC 2 Step C 6ES7 315–2AF00–0AB0 04.02.14
1100 PLC 3152DP with ASPC 2 Step D 6ES7 315–2AF01–0AB0 03.10.23
1200 PLC 3152DP with ASPC 2 Step E 6ES7 315–2AF01–0AB0 03.10.23
6ES7 315–2AF03–0AB0 FW1.2 12.30.10
1400 PLC 314C2DP with IBC 16 6ES7 314–6CF00–0AB0 FW1.0.2 10.60.20
2200 PLC 317-2DP with IBC 32 6ES7 317–2AJ10–0AB0 FW2.1 20.71.15
MCI 1 (840Di) PLC 3152DP with ASPC 2 Step E 6ES7 315–2AF03–0AB0 FW1.0 04.20.36
MCI 2 (840Di)
2100
PLC 317-2DP with IBC32 6ES7 317–2AJ10–0AB0 FW2.1 20.70.17
