Strata CIX 100 - Pad Group Assignment

System
PAD Values
Strata CIX Programming Vol.1 12/09 4-31
System
108 PAD Group Assignment
Prerequisite Program: None
You can enter up to 32 additional device groups to the PAD table to deal with exceptions to the default
table.
F
IELD DESCRIPTION
00 PAD Group Device
Type
Enter the Device Type.
Possible values:Station, Analog trunk, T1 trunk, ISDN trunk, CONF
bridge, Music source, EXT. paging
(default = no value.)
01 PAD Group Number Enter the PAD Group Number.
Possible values:0~6 (CIX100)
0~10 (CIX200, CIX670 Basic, CIX1200 Basic)
0~32 (CIX670 Exp, CIX1200 Exp)
(default = 0)
Table 4-2 Program 108 PAD Group Device Type Examples
Device Type Possible Values
Station 0~99999 (PDN)
ISDN Trunk Channel Group No. 1~128
Analog Trunk, T1 Trunk Trunk Number 1~264
Conference Bridge None (Conference Bridge is only one)
Music Source Music Port 1~15
External Paging Device Zone Relay Number 1~8
