Trunks
6-14 Strata CIX Programming Vol.1 12/09
310 DIT Assignment
Prerequisite Program: 300 page 6-7
This program assigns DIT Number Analysis Table for DIT trunks. DIT trunks are ground and Loop start
trunks.
1. Select Trunk > Trunk Assignments, DIT tab.
2. Enter Trunk equipment number field. Enter Program 310 data.
• List – to view a summary list of programmed trunks timers.
• Copy – to copy to trunk timer ports.
3. Click Submit.
F
IELD DESCRIPTION
Line No. Enter the trunk equipment number. Equipment numbers are required when
assigning a new trunk to the system. It can also be used to display the
equipment location of existing trunks.
Enter data as XXYYZZ:
• XX=cabinet 01~12
• YY=slot 01~10
• ZZ=analog trunk circuit 01~08
or
• ZZ=T1channel 01~24.
Example: If a line should be assigned to an RCOU in cabinet shelf 5, slot 2,
circuit 3, enter 050203.
Cabinet numbers:
• CIX100: Base, Exp.01
• CIX200: Base 01, Exp.02
• CIX670: Base 01, Exp 02~07.
• CIX1200: Base 01, Exp 02~12
Slot numbers:
• CIX100: Base 01, Exp.05~08
• CIX200: Base/Exp.01~04
• CIX670/1200: Base 01~08
• CIX670/1200: Exp.01~10
CTX28 and CIX40 assignments below are hard coded and cannot be changed.
01, 02 - 3 CO lines on motherboard - 28, 40 R1HW, 4 CO lines - 40 R2HW
01, 05 – GVMU - 28, GVPH - 40 R1HW, GIPx, MIPU or GCOCIH - 40 R2HW
01, 06 – GIPx, MIPU16 or GCOCIH - 40 R1HW, no card - 28, 40 R2HW
01, 08 - 3 CO lines on GCDU - 28, 40 R1HW and R2HW.
