Strata CIX 100 - Telephone Button Commands

Telephone Button Programming
Telephone Button Overview
13-2 Strata CIX Programming Vol.1 12/09
Telephone Button Commands
1. Use the following buttons to execute the commands:
• Hold – Enter.
• Page/Scroll – Scroll up or down.
• Speaker – This delimiter moves cursors between sub-parameter values.
• Volup – Escape. Vols displays as & on the LCD. Press Volup to program # or * in dialing
sequences.
• Voldown – Back space for line editing.
• # # Hold – Cancel.
• * – Use this button between values to specify a range of objects to be programmed (e.g., 1001*1005
enables programming of stations 1001 through 1005).
• ** – Use this button between values to specify a set of objects to be programmed (e.g.,
1001**1005**1012 enables programming of stations 1001, 1005 and 1012).
• Off-hook – lift and replace the handset to immediately exit programming mode.
2. Keep the following in mind as you maneuver through Strata CIX programs.
• Default and/or current settings are displayed on the telephone LCD with an asterisk.
• Some Strata CIX programs have more than 20 programmable parameters. To toggle from
parameters FB01~FB20 and FB21~FB40 press the Scroll or Page button after entering Program
Mode.
• To view parameter options on your telephone LCD press the desired FB button and press the Scroll
or Page button.
• Each parameter shows a number to the left (e.g., 2:DISABLE). Program the desired parameter by
pressing the number button (in this example 2) that corresponds to your desired parameter.
• To enter data, use the number keys.
• To submit your program entry press Hold. To confirm a submitted entry, press Hold again.
• To exit a program press # # Hold.
• To enter the # character in your data string press the Volup and the # button simultaneously. An &
sign appears in your LCD. Press the # button, then enter the remaining data.
• If you get an error code, press Hold (twice) to continue programming. See System Error Codes in
the Error Code document for error code details.
Programming Parameters
Programs can have between one and 40 programmable parameters, each represented by the FBnn
buttons. The LEDs light up for each FBnn button that features a programmable parameter. Each
parameter is programmed by entering values into the LCD from the telephone button pad.
1. At the SELECT PARAM prompt, press the appropriate FBnn button.
2. Enter the appropriate value from the telephone button pad using the Parameter Fields tables supplied
with each program.
3. Press Hold to submit.
4. Press another FBnn button to program more parameters
… or press Hold again to program.
