Services
External Devices
Strata CIX Programming Vol.1 12/09 9-53
503 Paging Devices Group Assignments
Prerequisite Program: 502 page 5-33
Assigns BIOU Page Zone Relays to Page Groups.
1. Select Station > Paging Devices.
2. Enter 00 Page Zone Relay Number.
3. Check the Paging Groups that you wish to activate.
4. Select the external generic relay number.
5. Click Submit.
F
IELD DESCRIPTION
00 Zone Relay Number Select the BIOU page zone relay that should be assigned to the page
groups below. This relay activates whenever the selected page group is
paged.
• BIOU1 = Zone Relays 1~4.
• BIOU2 = Zone Relays 5~8.
Possible values:1~8 (default = no value)
01-16 Page Groups
17 All Page Group
18 All Call
Emergency Page
Group
Check the box if the selected BIOU page zone relay should activate with
this page group.
Possible values:On or Off (default)
19 BGM Mute Relay
20-27 PG17~24 (CIX1200
Exp)
Assign BIOU generic relay as the BGM mute relay. This relay activates
whenever the external page is in use
• BIOU1 = Generic Relays 1~4.
• BIOU2 = Generic Relays 5~8.
Possible values:1~8 (default = 0)
Note The CIX100 ACTU or CIX built-in relay is programmed as relay 5.
For this relay operation, BIOU2 is installed, as default, in a virtual
equipment position - Cabinet 2, Slot 5, PCB code 20, in Program
100. To install an actual BIOU2 and disable the ACTU built-in
relay, use the programming telephone to remove the virtual BIOU2
and then install the actual BIOU2 in Cabinet 01 Slot 01~08 in the
normal manner.
