Trap Destinations (IP Trap Setup)
10-22 Strata CIX Programming Vol.1 12/09
Trap Destinations (IP Trap Setup)
Prerequisite Program: None
This program enables you to setup Trap IP Destination.
1. Select Alarm/Traffic > Alarm Setup > IP Trap Destination.
2. Select a Trap IP Index number or click Add to add a Trap IP index.
3. Click Submit.
F
IELD DESCRIPTION
IP Address Enter the IP address for remote connection. This is the IP address of the CIX
eMonitor PC or server or other trap monitor device.
Possible values:a.b.c.d.; a = 0~255, b = 0~255, c = 0~255, d = 0~255
Community Name Enter the Name of the Community.
This is the name assigned to the trap monitor PC or server. This is not a
password. It is only used to identify the location of the trap monitor device. The
default name for eMonitor is ‘eMonitor’ however any name can be used, such
as a location name (i.e.; Aledo).
Possible values:Alpha characters (default = no value).
