All ISDN Trunk Trace
Program start/stop of packaged detailed collection of event trace functions. This program is only available
in the telephone button programming mode.
Program Number(s): 905
Prerequisite Program: Format/Unmount Secure Digital/SmartMedia on page 13-14, ISDN Trace Location
on page 13-11 and Event Trace Control on page 13-9
Reference: Install SmartMedia card
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press Hold.
At the PROG= prompt enter 905 and press Hold.
1. Press FB01.
2. Select 1, or 2 to turn on or off.
3. Press Hold twice to execute.
4. Press # # Hold to return to the PROG= prompt.
5. Enter another program number to continue programming or press # # Hold again to exit programming
mode.
Event Trace Side Change
This program enables you to manage your ISDN protocol trace. This program is only available in the
telephone button programming mode.
Program Number(s): 906
Prerequisite Program: Format/Unmount Secure Digital/SmartMedia on page 13-14
Reference: Install SmartMedia card
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press Hold.
At the PROG= prompt enter 906 and press Hold.
1. Press FB01.
2. Select 1, 2, or 3 to select parameter.
3. Press Hold to execute.
4. Press # # Hold to return to the PROG= prompt.
5. Enter another program number or press # # Hold again to exit programming mode.
Note When the CIX1200/CIX670 stops logging data, it automatically sends data to the Secure Digital or
SmartMedia card. Run the Unmount command (Program 908) before removing the Secure Digital or
SmartMedia card to ensure complete data transfer.
FB Name FB Summary Value LCD Prompt
Trace All
ISDN Trunks
01
Output All ISDN Trunk Events to
SmartMedia
1:On (default)
2:Off
1:ON
2:OFF
FB Name FB Summary Value LCD Prompt
Side
Change
01
Enter desired parameter number 1:Message
2:ISDN
3:Message+ISDN
1:MESSAGE
2:ISDN
3:MESSAGE+ISDN
