Strata CIX 100 - Station PDN Auto-programming; CO Line Auto-programming

Strata CIX Programming Guidelines
Use Default Auto-programming to Start Up
Strata CIX Programming Vol.1 12/09 1-3
Strata CIX
Programming
Station PDN Auto-programming
When auto programming recognizes installed station PCBs, it assigns PDNs in numerical order as follows:
• Auto programming assigns PDNs to station PCB equipment numbers (cabinet, slot, circuit) in
equipment number order. All installed station PCB circuits will be assigned a PDN regardless of the
circuit type, digital (BDKU/BDKS, PDKU) or analog (RSTU). MIPUs, GIPUs and LIPUs are not
assigned PDNs.
• PDN 200 or PDN 2000 (depending on the system size) is assigned to the station circuit having the
lowest equipment number in the system. The PDN is then incremented by one digit and assigned to the
next highest station equipment number and so on. See Table 1-2.
• Program 205 Feature Button Setting – A Primary DN (PDN) is assigned to FB01 on each digital
telephone according to its equipment number (cabinet, slot, circuit) position. DND is assigned to FB20
on 20-button telephones. DND is not assigned on 10- and 14-button telephones.
CO Line Auto-programming
Table 1-3 shows the CO line PCBs that will be recognized and set in Program 100 during auto-
programming. The default data for CO line Incoming Line Groups (ILG), Outgoing Line Groups (OLG), and
CO line service type is set as shown in Table 1-4.
Important! PCBs must be installed per the rules in the Strata CIX and MAS Installation and
Maintenance Manual.
Table 1-2 Auto-Programming for Station Primary Directory Number
First digit CIX Basic Processor CIX670 Exp Processor/CIX1200
2
Primary DNs (3-digits)
200~299 depending on quantity of station
PCBs installed
Primary DNs (4-digit)
2000~2571 depending on the quantity of station
PCBs installed
3
Primary DN (3-digits)
300~399 depending on the quantity of
station PCBs installed
Table 1-3 Auto-Programming for CO line PCB Recognition (Program 100)
PCB
Code
PCB Name PCB Circuit Type Parameter setting Comments
000 - No PCB or RRCU None or Remote cabinets
001 RCOU, RGLU 4 analog Loop or
Ground start lines
Direct Incoming Termination (DIT) lines
005 RCOU+RCOS 8 analog Loop start
lines
Direct Incoming Termination (DIT) lines
006 RDDU 4 analog DID lines Direct Inward Dial lines
007 RDTU2 16 or 24 digital T1
lines
PCM Highway:
16 or 24
1
T1 Direct Incoming Termination (DIT)
lines
