Services
Destination Restriction
9-26 Strata CIX Programming Vol.1 12/09
Destination Restriction
Program Number(s): 532, 533, 534 and 111
Assign Destination Restriction (DR) features for the Strata CIX.
1. Select LCR/DR > Destination Restriction.
2. Enter 00 DR Level (DRL).
3. Enter Program 532 data.
4. Enter Program 533 data. Click List to view a summary list of programmed Dial Strings.
5. Enter Program 534 data. Click List to view a summary list of programmed Dial Strings.
6. Enter Program 111 data.
7. Click Submit.
532 DRL Table Allow/Deny Definition
Prerequisite Program: 533 below.
Specify the Destination Restriction (DR) Table Type using this command.
533 DRL Table Assignment
Prerequisite Program: None
This program adds or deletes entries in the DR Table associated with the DRL entered in Step 2 above.
F
IELD DESCRIPTION
00 Destination
Restriction Level
(DRL)
Select the DRL Number.
Possible values:1 ~ 16 (default = no value)
01 Type of Table Specify whether this DR Table is an allow table or deny table.
Possible values:Allow or Deny (default)
F
IELD DESCRIPTION
00 Destination
Restriction Level
(DRL)
Choose the DRL.
Possible values:1 ~ 16 (default = no value)
01 Dial String Enter the string of dialed digits to be allowed or denied. Wild cards (X and
N) can only be assigned through Network eManager, not the programming
phones.
Possible values:1~7 digits (default = no value)
02 Add/Delete Add or delete the string entered in 01 Dial String above to the DR Table.
Possible values:Add or Delete (default)
