Data Backup and Restore
System Turn-on and Start-up Time
14-4 Strata CIX Programming Vol.1 12/09
System Turn-on and Start-up Time
When a Release 4.0 or later system is turned on, it takes about 30-90 seconds to operate. CIX Release 2.x
and 3.x take about 15 seconds.
R3.0 and Earlier Data Backup
This section provides Strata CIX maintenance procedures that can be activated from the programming
telephone. These procedures are for R3.0 and earlier systems.For SmartMedia, refer to “Format/Unmount
Secure Digital/SmartMedia” on page 13-12.
1. Format the SmartMedia using “Format/Unmount Secure Digital/SmartMedia” on page 13-12 (Program
908).
2. Insert the formatted SmartMedia into Strata CIX.
3. Backup data using “Data Backup” on page 13-14 (Program 910). LED indicators should show the
following:
• FB01~FB03 solid red light.
• FB04 intermittent green.
4. Press FB01 and choose Backup by pressing 1 on the telephone button pad.
CAUTION! Never use Restore (2). It is not valid for current versions of CIX software and could
result in corrupt databases and system mis-operation.
5. Press Hold. Backup for programmed data starts. The LED indicator FB04 consistently blinks green
during back up. After back up is complete, FB04 will flash inconsistently slower.
CAUTION! Do not press Hold while Backup is being performed.
6. Press Hold twice to exit programming.
Backup Progress and Completion Indicators
You can monitor Backup progress by pressing the FB02 or FB03 buttons as follows. See “IP
Configuration” on page 13-18 for more details.
• If the value displayed in the LCD is increasing each time FB03 is pressed, the Backup is proceeding
successfully.
• When the value displayed in the LCD for FB03 and FB02 are the same, the Backup process is
complete.
• When the FB04 LED returns to an intermittent green, Backup is complete.
• Press FB04 to verify Backup is completed. If the LCD displays *1:ALL_OK the Backup was successful.
