9-46 Strata CIX Programming Vol.1 12/09
577 Caller History
Prerequisite Program: None
This command assigns which station stores Caller ID information for PDN,CO,GCO and POOL line
buttons.
1. Select Station > Call History Store Terminal.
2. Get Default - sets all data to factory defaults.
3. Click Submit.
650 Behind Centrex Assignment
Prerequisite Program: None
This feature allows Strata CIX to connect to the station side of a PBX or Centrex using a physical loop
trunk interface. DR and Least Cost Routing may need to account for access codes required by the PBX or
Centrex before connecting to the public network.
1. Click Advanced Configuration > Miscellaneous > Behind Centrex Assignment.
2. Get Default - sets all data to factory defaults.
3. Click Submit.
F
IELD DESCRIPTION
Ckt Type/Number Enter the Circuit Type and number. See the Table 9-2 below.
Possible values:Up to 6 digits (default = no value)
01 Primary DN Enter Station DN for which to store call history data.
Possible values:Up to 5 digits (default = no value)
Table 9-2 Circuit Type Code Definitions
Circuit Name Circuit Type Circuit Number Example
DN 1 0~99999 (DN) if DN is 200, value is 1200
CO 2 1~264 (Trunk Number) if CO is 30, value is 230
GCO 3 1~128 (GCO Key Group Number) if GCO is 50, value is 350
POOL 4 1~128 (POOL Key Group Number) if POOL is 80, value data is 480
F
IELD DESCRIPTION
00 OLG Number Select OLG that is attached to a Centrex (or other PBX).
Possible values:0~32 (CIX100), 0~50 (CIX200, CIX670/CIX1200 Basic),
0~128 (CIX670 Exp/CIX1200 ExpA), 0~220 (CIX1200
ExpB) (default = 0)
01 Behind Centrex Enable Behind Centrex Operation for this OLG.
Possible values:Enable or Disable (default)
02 Assume 9 Enable the Assume 9 feature.
Possible values:Enable or Disable (default)
03 Pause Timer Enter the number of seconds (0~5) the CIX will wait for second dial tone
from Centrex/PBX. Possible Value: 0~5 (default = 0
