9-34 Strata CIX Programming Vol.1 12/09
670 Remote Node Data Assignment
System Availability: Not available with CTX28
This command assigns the Remote node data (requires R1.3 and higher).
1. Select > Strata Net > Remote Node Data.
2. Enter Program 670 data.
3. Get Default - sets all data to factory defaults.
4. Click Submit.
651 Private Routing Plan Analysis
System Availability: Not available with CTX28
Prerequisite Program: 656 page 9-33 and 306 page 6-5
Assigns the Node IDs to Route Choice Tables for Private Networking.
1. Select > Strata Net > Route Plan Analysis.
2. Enter the node ID number (six digit numeral) to add to the Private Routing Plan Analysis Table.
Click List to see a summary list of programmed Node IDs or click Copy to copy data from an existing
node ID. Get Default sets all data to factory defaults.
3. Select the Private Route Choice Table in which to add the node ID entered in Step 2 above. Possible
values are 1~64, 0 = Delete and default = 0.
4. Click Submit.
F
IELD DESCRIPTION
00 Remote Node ID Enter the Remote Node ID for this node.
Possible values:Up to 6 digits (default = no value)
01 Remote Node IP
Address
Enter the remote node IP address.
Possible values:Up to 15 digits (default = no value)
02 Remote Node Port
Number
Enter the Remote Node port number for this node.
Possible values:0~65535 (default = no value)
F
IELD DESCRIPTION
00 Node ID Enter the node ID to be associated with a private route choice table
number.
Possible values:1~64 (default = no value)
01 Pvt Ntwk Route
Choice Table
Numbers
Enter the private route choice table number to be associated with this node
ID. Entering 0 deletes the node ID.
Possible values:1~64, 0 = delete (default)
