Station
Assignment
Strata CIX Programming Vol.1 12/09 5-35
Station
Paging Group Table View
Paging Group Table View enables you to view all paging groups and its members.
To access the Paging Group Table View
Select Station > Paging Group Table View, or if you are in Prog 502, click Terminal Paging Group Table
View.
See Table Views in Chapter 2 for table functionality.
For functionality on Delete, Add, Select All and Unselect All, refer to ”Hunt Group Table View’ on page 5-32
Note The Add button works a little different on this table. When you click Add, the Add dialog box
displays. Select the entry by clicking on it and then click the Add Now button.
210 Pickup Group
Prerequisite Program: 200 page 5-1
The Call Pickup Group assignments specify which group numbers this station will participate in when either
the Group Call Pickup or the Group Directed Call Pickup features are invoked. A user may be assigned to
more than one group.
1. Select Station > Pickup Group.
2. Enter a DN in the Primary DN field or select an existing record by clicking one of the following buttons:
• List – select from a summary list of programmed DKTs on the right side of the screen.
• Copy – Enter a DN in the Primary DN field and click Copy. Enter a new DN(s) to assign existing
Paging Group settings.
• Get Default - Sets all data to factory defaults.
3. Select the desired values. See descriptions below.
Click Submit
Pickup Group Table View
Pickup Group Table View enables you to view all Pickup groups and members.
To access the Paging Group Table View
Select Station > Pickup Group Table View. If you are in Prog 210, click the Call Pickup Group Table View
button.
See Table Views in Chapter 2 for table functionality.
For functionality on Delete, Add, Select All and Unselect All, refer to ”Hunt Group Table View’ on
page 5-32.
Note The Add button works a little different on this table. When you click Add, the Add dialog box
displays. Select the entry by clicking on it and then click the Add Now button.
F
IELD DESCRIPTION
01~48 Click in the radio button to Indicate which Call Pickup Group(s) this station
is to participate in. A station can be assigned to more than one group.
Possible values:check = On; or unchecked = Off (default)
Note 01~05 CIX40/100 and CTX28, 01~10 CIX200/670/1200 Basic,
01~32 CIX670 Expanded, 01~48 CIX1200 Expanded.
