Strata CIX 100 - Sip Trunk Service Assignment

Trunks
Trunk DID/DNIS Setup Wizard
Strata CIX Programming Vol.1 12/09
6-55
Trunks
328 SIP Trunk Service Assignment
Prerequisite Program: 100; 304; 309; 306; 326, 327
This tab must be completed before entries can be made for the URI tab. If this tab is not completed, entries
attempted in the URI tab will not be saved.
1. Select IP-Telephony > SIP Trunking, Service Assignment tab.
Important! After URI entries are made in the next tab (URI), changes to this program (Prog 328), will
DELETE all the URIs programmed. Once this is set, do not change it.
2. Make the required entries for Channel Groups.
3. Click Set.
F
IELD DESCRIPTION
00 SIP Trunk Channel
Group
Select a Channel Group Number:
Possible values:1~32 (CIX40), 1~32 (CTX100), 1~48 (CTX670 Basic & CIX200),
1~128 (CTX670 Exp), 1~ 48 (CIX1200 HCTU only), 1~128
(CIX1200 HCTU+HEXAU), 1~220 (CIX1200 HCTU +HEXBU),
(default = no value)
02 Service Index Assign a SIP Trunk Service by selecting its SIP Trunk Service Kind (PRG327)
Table Index.
Possible values:1~32 (CIX40), 1~32 (CIX100), 1~48 (CIX200/CIX/670 Basic/
CIX1200 Basic), 1~128 (CIX200/CIX/670 Exp/CIX1200 Exp).
