Strata CIX 100 - 202 ISDN BRI Station

Station
Assignment
5-42 Strata CIX Programming Vol.1 12/09
ISDN
The following programs assign ISDN data to stations.
Program Number(s): 202 and 217
202 ISDN BRI Station
Prerequisite Program: 100 page 4-1
This command assigns ISDN BRI stations.
1. Select Station > Basic ISDN.
2. Enter a Primary DN for an existing record or click one of the following buttons:
• List – view a summary list of programmed DNs.
• Create – Assign a new Primary DN with custom BRI Station settings.
• Copy – Enter a DN in the Primary DN field and click Copy to make a new DN assignment with BRI
Station settings copied from the DN entered in the Primary DN field.
• Delete – Enter an ISDN Primary DN to delete and click OK.
• Change DN – Enter a DN in the Primary DN field and click Change DN to assign a new DN to the
ISDN BRI Station.
• Get Default - Sets all data to factory defaults.
3. Set up ISDN BRI Station using the Program Detail table below.
4. Click Submit.
F
IELD DESCRIPTION
Primary DN Enter the PDN. When a required DN is not programmed, the DN is regarded as a
new station. The system assigns default data as defined in 217 ISDN Station Data
.
Possible values:Up to 5 digits (default = no value)
01 PDN Equipment No. Enter the BRI equipment number assigned to this PDN. This is the cabinet, slot,
and circuit number of the RBUU/RBUS or RBSU/RBSS interface PCB to which the
PDN is or should be, assigned. Enter data as xxyyzz:
Example: If the PDN should be assigned to a BDKU in cabinet 5, slot 2, circuit 3,
enter 050203.
Cabinet numbers:
CIX100: Select 01 for Base and Exp cabinet.
CIX200: Select 01 for Base and 02 for Exp cabinet.
CIX670: Select 01 for Base and 02~07 for each Exp cabinet.
CIX1200: Select 01 for Base and 02~12 for each Exp cabinet
Slot numbers:
CIX100: Select 01~04 for Base slots and 05~08 for Exp slots.
CIX200: Select 01 ~ 04 for either cabinet.
CIX670: Select 01~08 for Base slots and 01~10 for Exp slots.
CIX1200: Select 01~08 for Base slots and 01~10 for Exp slots
02 ISDN Channel Group Enter the ISDN Channel Group number.
Possible values:1~32 (CIX100), 1~48 (CIX200, CIX670 Basic)1~128 (CIX670
Exp), 1~48 (CIX1200 Basic), 1~128 (CIX1200 Exp A), 1~220
(CIX1200 Exp B) (default = 1)
