Strata CIX 100 - Sip Trunk Service Kind Assignment

Trunks
Trunk DID/DNIS Setup Wizard
6-50 Strata CIX Programming Vol.1 12/09
327 SIP Trunk Service Kind Assignment
Prerequisite Program: 100; 304; 309; 306; 326
This tab is where the SIP trunk provider is defined. There may be several SIP trunk providers per channel
Group.
1. Select IP-Telephony > SIP Trunking - Service Definition tab.
2. Setup the SIP trunk service kind table index by adding values to the remaining fields.
3. Click Submit.
F
IELD DESCRIPTION
00 SIP Trunk Service Kind
Table Index
Create a SIP Trunk Service Kind Table Index by selecting.
Possible values:1~32 (CIX40), 1~32 (CIX100), 1~48 (CIX200, CIX670 Basic &
CIX1200 Basic), 1~128 (CIX200, CIX670 Exp, CIX1200 Exp)
01 Registration Mode Only Client or None can be assigned.
02 ILG The incoming line group number for this service. Note that the ILG number can
only be assigned to one service.
Possible values:1~32 (CIX40), 1~32 (CTX/CIX/100) 1~50 (CIX200) 1~50 (CTX/
CIX 670 BCTU only or BBCU only) 1~128 (CTX/CIX670 BCTU
+ BEXU or BBCU + BECU) 1~50 (CIX1200 HCTU only) 1~128
(CIX1200 HCTU + HEXAU) 1~220 (CIX1200 HCTU + HEXBU)
03 OLG The outgoing line group number for this service. Note that the OLG number can
only be assigned to one service.
Possible values:1~32 (CIX40) 1~32 (CTX/CIX/100) 1~50 (CIX200) 1~50 (CTX/
CIX 670 BCTU only or BBCU only) 1~128 (CTX/CIX670 BCTU
+ BEXU or BBCU + BECU) 1~50 (CIX1200 HCTU only) 1~128
(CIX1200 HCTU + HEXAU) 1~220 (CIX1200 HCTU + HEXBU)
04 Effective Channel
Number
Sets the number of channels that will be used with this service. Setting this value
to 0 will delete the SIP Trunk service index.
Possible values:0~96 (CIX40) 0~96 (CTX/CIX/100) 0~176 (CIX200) 0~176
(CTX/CIX 670 BCTU only or BBCU only) 0~264 (CTX/CIX670
BCTU + BEXU or BBCU + BECU) 1~176 (CIX1200 HCTU only)
1~264 (CIX1200 HCTU + HEXAU) 1~440 (CIX1200 HCTU +
HEXBU)
05 Domain Name Domain name for the service provider. Maximum of 64 characters.
06 SIP Server SIP Server Domain Name or IP address. (Used for registration and outbound
proxy).
07 Primary Voice Packet
Configuration
Primary Voice packet configuration table (Prog 152) index.
08 Secondary Voice Packet
Configuration
Secondary Voice packet configuration table (Prog 152) index.
09 Registration Period After successful registration, re-registration will occur after this many seconds.
Possible values:700~99999
