Station
Assignment
Strata CIX Programming Vol.1 12/09 5-31
Station
218 Station Hunt Assignments
Prerequisite Program: 209 page 5-29
This program assigns station DNs to hunt groups using Program 209 and assigns the rotation order in
which DNs are hunted.
1. Select Station > Hunt Group.
2. Click on the Member tab.
3. Enter a Member Number for an existing record or click one of the following buttons:
• List –Select from the list of programmed hunt groups on the right side of the screen.
• Insert – Assign a new station DN to the hunt group number entered above.
• Append – Assign a new DN as the last DN in a hunt group’s hunt order.
• Modify – Highlight an existing DN in the hunt order and change the station DN assignment.
• Delete – Delete station DN assignment to Hunt Order number.
• Get Default - Sets all data to factory defaults.
4. Click Submit.
F
IELD DESCRIPTION
Hunt Group Number Enter an existing hunt group number or use the List, Add, Append, Modify, or Delete
buttons as described above.
Possible values:0~18 (CTX28), 0~32 (CIX40), 0~90 (CIX/CTX100), 0~200 (CIX/
CTX670 & CIX200 Basic), 0~640 (CIX/CTX670 Exp), 0~200 (CIX1200
Basic HCTU only),
Possible values:0~1100 (CIX1200 Exp. HEXAU or HEXBU) (default = no value)
Hunt Order This field assigns a station DN position within a hunt group’s hunt order. The hunt order
is selected automatically by Strata eManager. Programmers should assign the last
station in the hunt order first and assign the first station in the hunt order last.
Possible values:1~72 (CIX100), 1~160 (CIX200, CIX670/1200 Basic),
1~560 (CIX670 Exp, CIX1200 Exp A), 1~1100 (CIX1200 Exp B)
(default = no value)
DN By selecting the Insert button you can add a new DN to the hunt group’s hunt order.
Enter the desired DN in the pop-up dialog box.
To modify an existing entry use the Modify button as described above.
Possible values:Up to 5 ASCII characters (default = no value)
Set Type Insert, Append, Modify (replace), Delete an existing assignment.
