Trunks
Trunk DID/DNIS Setup Wizard
6-56 Strata CIX Programming Vol.1 12/09
329 SIP URI Assignment
Prerequisite Program: 100; 304; 309; 306; 326, 327, 328
The SIP URI is the telephone number provided by the SIP service provider. When the number is dialed
from the outside, the provider sends a SIP INVITE just as if it were a call to a SIP station.
1. Select IP-Telephony > SIP Trunking, URI tab.
2. Enter the information required as specified in the table below.
3. Click the action to perform: Add, Modify, or Remove.
F
IELD DESCRIPTION
00 SIP URI Trunk Service
Index
The Prog 327 index for the service kind associated to this SIP URI.
Possible values:1~32 (CIX40), 1~32 (CIX100), 1~48 (CIX200/CIX/670 Basic/
CIX1200 Basic), 1~128 (CIX/670 Exp./CIX1200 Exp)
01 URI Index The Index into the table of URIs There are a maximum of 160 per card.
Possible values:1~72 (CIX40), 1~72 (CIX100), 1~160 (CIX200/CIX/670 Basic/
CIX1200 Basic), 1~160 (CIX/670 Exp./CIX1200 Exp).
02 SIP URI The user portion of the SIP URI. The host portion is assigned by Prog 327 field 5.
03 SIP URI User Name The user name used for authentication of this URI.
04 SIP URI Password The password used for authentication of this URI
05 SIP URI Channel
Group
0 (recommended) means the channel group is picked out from Prog 328.
Otherwise, this SIP URI is registered through the specifically set channel group.
06 SIP URI Attribution MAIN specifies that this URI will be registered with the service provider. SUB
indicates that this URI will not be registered.
