515 View BIOU Control Relay Assignments

Prerequisite Program: 100 page 4-1, and 105 page 4-15

This assignment is used to view functions of the four control relays on each BIOU set in Program 105 12

Night Relay and 18 Night Bell Relay; Program 508 Door Lock Control Assignment; and Program 503 19

BGM Mute Relay. The system allows up to two BIOUs to provide a total of eight control relays. The control

relays can be configured as an external BGM mute control, Night Bell control, Night Mode Control, and

Door Lock Control.

Notes

• BIOU-1 relays are identified as Control Relays 1~4.

• BIOU-2 relays are identified as Control Relays 5~8.

1. Select System > BIOU Relay Type.

2. Enter Program 515 data.

3. Get Default - sets all data to factory defaults.

4. Click Submit.

IELD DESCRIPTION

00 BIOU (1 or 2) Enter the BOIU number.

Possible values:1 or 2 (default = no value)

Note BIOU 1 and BIOU 2 are assigned in Program 100 - Card Assignment.

01 BIOU Relay 1 or 5;

or CIX100

02 BIOU Relay 2 or 6

03 BIOU Relay 3 or 7

04 BIOU Relay 4 or 8

View the function of BIOU1, control relay 1 or BIOU2, control relay 5:

View the function of BIOU1, control relay 2 or BIOU2, control relay 6:

View the function of BIOU1, control relay 3 or BIOU2, control relay 7:

View the function of BIOU1, control relay 4 or BIOU2, control relay 8:

Possible values:Not Use, Ext Paging, Night Bell, Night Relay or Door Lock

(default = no value)

• NOT USE – if the relay is not used.

• PAGE MUTE – External BGM mute control activates during an external

page (see “503 Paging Devices Group Assignments” on page 9-53).

• NIGHT BELL – Night bell control activates during the system night mode

only when incoming CO lines ring (see “102 Flexible Access Codes” on

page 4-3).

• NIGHT RELAY – Night mode control activates continuously during the

system night mode (see “105 System Data” on page 4-15).

• DOOR LOCK – Door lock control activates when a telephone's door unlock

button is pressed (see “508 Door Lock Control Assignment” on page 9-50).
