Telephone Button Programming
900 Series Programs
Strata CIX Programming Vol.1 12/09 13-13
Telephone Button
Programming
.
1. Press FB01 to enter parameter. Enter 1~4 as your command choice. Press the Scroll or Page button
to make your selection.
2. Press Hold to confirm and Hold again to execute.
3. Wait for the PROG= prompt to appear before proceeding.
4. Enter another program number to continue programming or press # # Hold again to exit programming
mode.
Strata CIX Secure Digital/SmartMedia Directories
Running the Normal and Forced options of this program creates five directories on the SmartMedia card as
follows:
• Admlog – The Admlog folder saves
• Errlog – System error logs are saved into this folder.
• Evnttrce – Strata CIX eManager Event Trace files are saved into this folder.
• Progdata – Your Strata CIX programmed settings are all saved in this folder.
• Program – The operating software and default data of the Strata CIX is saved in this folder.
When a backup is performed, Strata CIX saves programmed data to the Progdata folder.
MAC Address (System Serial Number)
This program enables you to display your CIX1200 or CIX670 System Serial Number.
Program Number(s): 909
Prerequisite Program: None
Reference: None
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press Hold.
At the PROG= prompt enter 909 and press Hold.
FB Name FB Summary Value LCD Prompt
Control
01 Choose SmartMedia card formatting method:
Normal – creates any Strata CIX SmartMedia directory
that does not exist already. Exiting directories are not
overwritten by this procedure.
Forced – erases any existing directories and files. All
existing data is overwritten. See Strata CIX Secure Digital/
SmartMedia Directories below for more information.
Unmount – writes data into SmartMedia Card. Always run
unmount before removing the SmartMedia card to prevent
damage to the card.
Transfer – writes data from static RAM to SmartMedia
Card.
1:Normal
2:Forced
3:Unmount
4:Transfer
1:NORMAL
2:FORCED
3:UNMOUNT
4:TRANSFER
