Telephone Button Programming
900 Series Programs
13-14 Strata CIX Programming Vol.1 12/09
1. Press FB01 to view parameter. The MAC Address is view only and cannot be changed.
2. Press Hold (twice) to exit to the PROG= prompt.
3. Enter another program number to continue programming or press # # Hold again to exit programming
mode.
Data Backup
This program enables you to Back up system data to a SmartMedia card.
Program Number(s): 910
Prerequisite Program: “Format/Unmount Secure Digital/SmartMedia” on page 13-12 must be performed
before running this program.
Reference: None
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press Hold.
At the PROG= prompt enter 910 and press Hold.
1. Press FB01 to enter your Backup choice. Press the Scroll or Page button to view selection options.
2. Press 1. FB01 and FB04 should blink green.
3. Press Hold to execute. Press Hold again to Cancel. This program stops running if you exit
programming mode from your telephone.
FB Name FB Summary Value LCD Prompt
MAC Address
01 Display System Serial Number. 12 digits MAC Address
FB Name FB Summary Value LCD Prompt
Backup
Function
01 Start and Stop system backup.
Restore function is not operational and
should never be executed. Use System
Initialize (Program 900) Level 1 to restore
system backup.
1:Backup
2:Restore (Do not
use. See Note on
left).
3:Cancel
1:BACKUP
2:RESTORE
3:CANCEL
Numbers
02 The number of data blocks. This number
varies depending on the amount of
programming the system contains.
Variable ALL NO=
Current
Number
03 This number increments as the backup
progresses. When the backup is complete
this number should match the total number of
data blocks displayed in Numbers (FB02).
Variable CUR NO=
Backup State
04 All_Ok – Backup completed with no errors.
Partial_Ok – Backup has completed with
errors.
NG – Backup has failed.
Cancel – Cancel Backup.
Importing – Program data is being restored.
Exporting – Program data is being sent out.
1:normal end all
2:normal end part
3:abnormal end
4:cancel
5:importing
6:exporting
