Event Trace Control

Strata CIX Programming Vol.1 12/09 11-3

Maintenance

903 Start/Stop Trace

904 ISDN Trace Location

ISDN protocol event trace collection conditions are established using this program.

Note This trace can be performed on BSU and PTU cards only.

905 All ISDN Lines Trace Level Selection

FIELD DESCRIPTION

Start/Stop Trace Click in the appropriate button to start or stop Message Trace. Start Trace

indicates that the system’s trace data collection process has begun. Stop

indicates the trace data collection process is terminated

Before removing the SmartMedia card run Program 908. See “908 Secure

Digital and SmartMedia” on page 10-5.

Possible values:Start Trace or Stop Trace (default)

Current Function Displays the last command sent to the CIX.

Completion Displays the progress of the current function.

Size [x16 Bytes] Set the trace data size. Toshiba recommends leaving this parameter at the

default setting which provides approximately 15 minutes of trace data.

Possible values:1~256 bytes with 1 unit = 16 bytes (default = 2)

Category Select Trace data type to be stored.

Possible values:Call Processing, Maintenance, and Call Processing and

Maintenance (default)

IELD DESCRIPTION

Cabinet/Slot/Circuit Enter the Equipment Location to be traced (xxyyzz).

Possible values:xx = Cabinet 01~11; yy = Slot 01~10; zz = Circuit 01~04

Trace Kind Select the trace collection level.

Possible values:LLCI Trace, Layer 3, Layer 2 & 3, State Transitions, Errors,

Layer 2 States.

Trace Level Select the extent to which the trace collects information.

Possible values:No Trace (default), Brief or Extensive

IELD DESCRIPTION

Trace Level For All

ISDN Lines

Select whether to trace all ISDN PRI and BRI trunks.

Possible values:Set Extensive (default) or Set No Trace
