IP Telephone Programming
IP Telephone Installation and Network Connection Setup
Strata CIX Programming Vol.1 12/09 8-21
IP Telephone
Programming
260 Full IP Station Assignment
Prerequisite Program: CABINET SLOT PCB ASSIGNMENTS
This command assigns IP station and MAS HMP resources to the GIPx, MIPU and LIPU/LIPS interfaces.
1. Select Station > Station Assignments, and click on the Basic tab.
2. Enter a DN number in the Primary DN field or click one of the following buttons:
• List – view a summary list of programmed DNs.
• Extended List – view a detailed list of programmed DNs.
• Create – Assign a new DN with custom settings by entering a DN value. Press OK, assign the PDN
Equipment No. and click Submit.
• Selective Copy – Enter a DN in the Primary DN field and click Selective Copy to make a new DN
assignment with settings copied from the DN entered in the Primary DN field.
• Delete – Enter a Primary DN or a range of Primary DNs to delete and click OK.
• Change DN – Enter a DN in the Primary DN field and click Change DN. Enter the new DN
assignment and click OK.
3. Setup the DN by adding values to the remaining fields.
4. Click Submit.
Note The max. number of IP telephones programmed on one MIPU (MIPU24) is 24; the GIPU8 is 8.
F
IELD DESCRIPTION
00 Prime DN Prime DN (enter an existing PDN or enter a PDN you wish to create for a new station).
01 Type Assign device types to GIPx, MIPU, LIPU/LIPS ports.
• IPT2000 series, IP5000 series telephones, and IP Softphones are IPT
(require End Point License).
• SIP telephones are SIP (require End Point license).
• IP Attendant Consoles are ATTENDANT (require Basic Port License).
• VM Ports are VOICE MAIL (require Basic Port License and MAS HMP
resource).
• ACD Announcers are ACD ANNOUNCE (require Basic Port License and
MAS HMP resource).
Note IPT1020 telephones cannot be assigned to GIPx, MIPU, LIPU/LIPS -
they must be assigned to a BIPU-M using Prog 200.
