Station
Assignment
5-38 Strata CIX Programming Vol.1 12/09
517, 519 Multiple Call Group Assignment
Multiple Call/Delayed Ringing which enables you to delay ring to voice mail and auto attendants.
1. Select Station > Multiple Calling Group.
2. Click Create. A dialog box displays.
3. Enter a calling group index in the dialog box.The calling group index can be:
1~16 (CIX100), 1~32 (CIX200, CIX670 Basic), 1~64 (CIX670 Expanded) 1~32 (CIX1200 Basic), 1-96
(CIX1200 Expanded)
4. Click OK. Parameter - 01 MC Group Pilot Number gets highlighted.
5. Enter the DN of the MC group. This number should not conflict with an existing telephone number.
6. Verify and change other parameters.
• Get Default - Sets all data to factory defaults.
7. Click Submit. The group index displays on the left of the program name.
F
IELD DESCRIPTION
Multiple Call Group Number Select a group number.
Possible values:1~16 CTX28, 1~16 CIX40, 1~16 CTX/CIX/100, 1~32 CIX200,
1~32 CTX/CIX 670 BCTU only or BBCU only, 1~64 CTX/
CIX670 BCTU + BEXU or BBCU + BECU, 1~32 CIX1200
HCTU only, 1~96 CIX1200 HCTU + HEXAU, 1~96 CIX1200
HCTU + HEXBU
01 MC Group Pilot Number Enter the pilot directory number that should be assigned to the Multiple Call
Group. This can be any number, 1~5 digits, that does not conflict with numbers
in the current system number plan.
Possible values:1~5 digits (default = no data)
02 Ring Delay 1 Timer Set the timer in seconds.
Possible values:1~180 (default = 12)
03 Ring Delay 2 Timer Set the timer in seconds.
Possible values:1~180 (default = 24)
04 System Call Forward Assign a system call forward template number to the multiple calling group.
Possible values:0~4 CIX/CTX100 & CTX28 & CIX40, 0~10 CIX/CTX670 &
CIX200 Basic, 0~32 CIX/CTX670 Exp., 0~10 CIX200 Basic
HCTU only, 0~48 CIX1200 Exp. HEXAU or HEXBU
(default = 0)
05 Voice Mail ID Enter the VM call forward ID digits for the multiple calling group.
Possible values:Up to 10 digits (default = no data).
To Next Page
