To view Backup progress
1. While the program is running (FB01 and FB04 blink green), press FB02 to view the total number of files
to be transferred.
2. Press FB03 to view the current file number that is being transferred.
3. The Backup is complete when FB04 blinks intermittently.
4. To verify success, push FB04. Your telephone LCD should indicate *1.ALL_OK.
5. Press # # Hold to exit.
Note Do not press the Hold button. Pressing the Hold button restarts the Backup procedure.
To Restore data from the SmartMedia card to Strata CIX, see “System Initialize” on page 13-5.
Program Update
This program enables you to update the Strata CIX programs.
Program Number(s): 911
Prerequisite Program: Format SmartMedia Card. Before running this program make sure the
SmartMedia card is properly formatted. See “Format/Unmount Secure Digital/
SmartMedia” on page 13-12 for more details.
Reference: None
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press Hold.
At the PROG= prompt enter 911 and press Hold.
FB Name FB Summary Value LCD Prompt
Update Function
01 Enter 1 or 2 to identify the type of Update
intended.
Select 3 to cancel a running update.
1:Update
2:Reboot
3:Cancel
1:Update
2:Reboot
3:Cancel
Total Blocks
02 View total blocks to be updated (total
blocks will vary depending on software
versions).
0~65536
(CIX1200/670)
0~128 (CIX100)
default = 0
n/a
Copied Blocks
03 View number of blocks copied. 0~65536
(CIX1200/670)
0~128 (CIX100)
default = 0
n/a
Active Side Status
04 Backup Type Display 1:Normal
2:Trial
3:Fault
4:Don’t Care
5:Error
1:Normal
2:Trial
3:Fault
4:Don’t Care
5:Error
Stand by Side
Status
05 Stand by Backup Type 1:Normal
2:Trial
3:Fault
4:Don’t Care
5:Error
1:Normal
2:Trial
3:Fault
4:Don’t Care
5:Error
