Trunks
ISDN
6-30 Strata CIX Programming Vol.1 12/09
302, 303 Strata Net (PRI) and Strata Net IP (QSIG)
Prerequisite Program: 100 page 4-1
The PRI (RPTU, BPTU) and Strata Net IP (BIPU-Q) interface cards need to have a number of assignments
for defining operation. These include assigning which channels are available for use and the location of the
D-channel or signaling channel. The D-channel exists on the circuit assigned in this command. Also, a
number of optional functional capabilities also need to be enabled or disabled.
For BIPU-Q channel groups, parameters 01~04 must be configured; all other parameters should remain at
default. All parameters should be configured for ISDN. Many of these are normally set to default.
Note PRI ILGs and OLGs are assigned using “ISDN Call-by-Call” on page 6-35. Therefore, ILG and OLG
must be set to 0.
1. Select Trunk > ISDN PRI.
2. Enter Channel Group number or click one of the following buttons:
• List – choose from the list of programmed trunks on the right side of the screen.
• Create – Assign a new trunk with default settings.
• Copy – Enter a Channel Group number and click Copy to make a new trunk assignment with
settings copied from the Channel Group entered.
• Delete – Delete a trunk
• Get Default - sets data to factory defaults.
3. Enter data.
4. Click Submit.
F
IELD DESCRIPTION
Channel Group Channel Group Number.
Assign the proper PAD levels to channel groups in Programs 107, 108 and 114.
These levels are critical for ISDN and Strata Net IP speech levels as well as
Quality Of Service.
Possible values:1~32 (CIX40), 1~32 (CTX100), 1~48 (CTX670 Basic &
CIX200), 1~128 (CTX670 Exp), 1~48 (CIX1200 HCTU only), 1-
128 (CIX1200 HCTU+HEXAU), 1~220 (CIX1200 HCTU
+HEXBU)
(default = 0)
