Strata CIX 100 - Make Busy Control

Telephone Button Programming
900 Series Programs
13-16 Strata CIX Programming Vol.1 12/09
1. Press FB01 to enter your Backup choice. Press the Scroll or Page button to view your selection
options.
2. Press 1. FB01 and FB04 should blink green.
3. Press Hold to execute. Press Hold again to Cancel. This program stops running if you exit
programming mode from your telephone.
Make Busy Control
When an error occurs in hardware resources used for a station or a line fails, this feature makes them
busy. The station or line card can be disabled temporarily to perform maintenance or parts replacements
as well. This program is only available in the telephone button programming mode.
Program Number(s): 912
Prerequisite Program: Format SmartMedia Card
Reference: None
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press Hold.
At the PROG= prompt enter 912 and press Hold.
At the CABINET= prompt enter the Shelf number.
Note The Shelf number is entered in “XX” format where Shelf is a two digit value from 01~07
corresponding to the Strata CIX Cabinet number. See “Program Button LEDs” below for a
description of the LED display.
1. Press FB01~FB10 to enter your Make Busy selection for the appropriate Slot in the Cabinet entered in
Access Sequence above.
Note The slot to which your programming phone is connected cannot be set to Make Busy.
Active Side
Number
06 Active Side Number. 0 or 1
default = 0
ACT SIDE=
Status
07 View Backup Status. 1:Idle
2:Running
3:Success
4:Error
1:Idle
2:Running
3:Success
4:Error
FB Name FB Summary Value
Equipment 00 Enter Cabinet Number 01~07 (value=xx)
Slot #1
01
Enter 1 or 2
1: Set make busy
2: Clear make busy
Slot #2
02
Slot #3
03
Slot #4
04
Slot #5
05
Slot #6
06
Slot #7
07
Slot #8
08
Slot #9
09
Slot #10
10
FB Name FB Summary Value LCD Prompt
