Strata CIX 100 - Incoming Line Group Assignment

Trunks
6-2 Strata CIX Programming Vol.1 12/09
304 Incoming Line Group Assignment
Prerequisite Program: None
This assignment is used to configure ILGs only, OLGs are configured in the Outgoing Line Group
Assignment 306. The same line can be placed in an ILG and OLG.
F
IELD DESCRIPTION
Group Number Enter the group number of the line group that should be configured.
Possible values:0~32 (CIX100), 0~50 (CIX200, 670/1200 Basic),
0~128 (CIX670 Exp, 1200 Exp A), 0~220 (CIX1200 Exp B)
(default = no value)
01 Group Type Select the ILG Type.
Possible values:Analog (default) or ISDN
02 Line Type Select the Trunk Type.
Possible values:CO (default) or Tie
03 CO Service Type Select CO Trunk Service Type.
Possible values:DID or DIT (default)
04 Private Service Type Select the Tie Trunk Service Type. This field is required when Trunk Type is
Tie.
Possible values:Standard (default) or StrataNet
05 GCO Key Number Select ILG GCO Key Group for DIT mode (see Trunk Type above). The same
GCO cannot belong to different ILGs.
Note: If CO keys are assigned in PRG205 to ring lines in this group, GCO
assignments will be ignored and will not ring
Possible values:0~32 (CIX100), 0~50 (CIX200, CIX670/1200 Basic),
0~128 (CIX670 Exp, 1200 Exp A), 0~220 (CIX1200 Exp B)
(default = no value)
06 Pooled Key Number Select ILG Pooled Line Key Group for DIT mode. The same Pooled Line Group
cannot belong to different ILGs.
Note: If GCO or CO keys are assigned to ring lines in this group, Pooled key
assignments will be ignored and will not ring.
Possible values:0~32 (CIX100), 0~50 (CIX200, CIX670/1200 Basic),
0~128 (CIX670 Exp), 0~220 (CIX1200 Exp)
(default = no value)
07 COS Select Class of Service Day 1, Day 2 and Night Values.
Possible values:1~32 (default = 1)
08 DRL Select Destination Restriction Level Day 1, Day 2 and Night Values.
Possible values:1~16 (default = 1)
09 FRL Select Facilities Restriction Level Day 1, Day 2 and Night Values.
Possible values:1~16 (default = 1)
