9-32 Strata CIX Programming Vol.1 12/09
510 COS Override Assignment
Prerequisite Program: 105 System Data
Assigns the COS, FRL, DRL and QPL to be used by COS Override. If a COS parameter has been
assigned in either the original or the override COS, it will be applied.
1. Select > LCR/DR > COS Override.
2. Enter Program 510 data or select a COS Override Index and click Copy to copy settings from the
selected COS Override Index.
3. Get Default - sets all data to factory defaults.
4. Click Submit.
F
IELD DESCRIPTION
00 COS Override Index Select the COS Override index.
Possible values:1~16 (default = no value)
01 COS Override Code Select the COS Override Code as entered by users. If no data is
entered in this field any previously entered data is erased.
Possible values:Up to 8 ASCII characters (default = no value)
02 Set COS Select COS number for this override code.
Possible values:1~32 (default = 1)
03 Set DRL Select DRL number for this override code.
Possible values:1~16 (default = 1)
04 Set FRL Select FRL number for this override code.
Possible values:1~16 (default = 1)
05 Set QPL Select QPL number for this override code.
Possible values:1~16 (default = 1)
06 Set Network COS Select Network COS index for this override code.
Possible values:1~32 (default = 1)
