Trunks
6-16 Strata CIX Programming Vol.1 12/09
309, 312 Direct Inward Dialing
This command assigns DID number analysis tables to ILGs.
1. Select > Trunk > DID.
2. Select an ILG Group Number.
3. Enter a DID Number in the 01 DID Number field or click one of the following buttons:
• List – choose from the list of programmed DIDs on the right side of the screen.
• Create – Make a new DID assignment using default settings.
• Copy – Enter a DID Number in 01 DID Number and click Copy to make a new DID assignment with
settings copied from the DID Number entered.
• Delete – Delete a DID.
• Get Default - restores data to factory defaults.
4. Enter DID Assignment data.
5. Click Submit.
F
IELD DESCRIPTION
ILG Group Number Select the ILG number.
Possible values:1~32 CIX40, 1~32 CTX/CIX/100, 1~50 CTX/CIX 670 BCTU only or
BBCU only, 1~128 CTX/CIX670 BCTU + BEXU or BBCU + BECU,
1~50 CIX1200 HCTU only, 1~128 CTX670 HCTU + HEXAU, 1~220
CTX670 HCTU + HEXBU (default = 0)
01 DID Number Enter a DID number.
Possible values:1~7 digits may include wild card “?” where “?” = 0~9 (default = no
value).
02 MOH Source Set Music On Hold source for the DID number. Quiet tone means no music on hold
for the selected DID number.
Possible values:Quiet Tone, External 1~15, or Internal (default)
03 GCO Key Group Enter GCO Key Group Number that should ring for this line group.
Note: If CO Key or Dialing Digits are assigned as a ringing destination this
assignment will be ignored and will not ring.
Possible values:1~6 CTX28, 1~32 CIX40, 1~32 CTX/CIX/100, 1~50 CTX/CIX 670
BCTU only or BBCU only, 1~128 CTX/CIX670 BCTU + BEXU or
BBCU + BECU, 1~50 CIX1200 HCTU only, 1~128 CIX1200 HCTU +
HEXAU, 1~220 CIX1200 HCTU + HEXBU
(default = 0)
