Trunks
Strata CIX Programming Vol.1 12/09 6-15
Trunks
01 Day1 Destination Type
02 Day2 Destination Type
03 Night Destination Type
Select Destination Type for each.
Possible values:No Data (default), Dialing Digits, DISA, Built-in Modem, or Night
Bell
• No Data – no destination will ring when the line rings into the system.
• Dialing Digits – assigns the line to ring the directory number or access code
defined in the Destination Digits assignment.
• DISA – assigns the line to ring in as a DISA call. DISA dial tone will be
returned to the caller.
• Modem – assigns the line to ring the remote maintenance modem on the CIX
processor. Used to call into the system with an eManager PC and modem.
• Night Bell – Assigns the line to cause the night relay to pulse (one-sec. close
/ 3-sec. open)
Day1 Destination Digits
Day2 Destination Digits
Night Destination Digits
Enter Destination, Directory Number or Access Codes for each, only if Dialing
Digits is selected as Destination Type.
• If Dialing Digits is the Destination Type, enter the Directory Number that the
line should ring. If the line should ring over external page, enter #31xx, where
xx is the external Page group number.
• If the default page access code #31 was changed, use the new page access
code as the leading digits.
• Line access codes and network routing numbers can also be entered to route
incoming calls back out to a public or private network number.
Possible values:Up to 32 digits (default = no value)
04 MOH Source Select the Music On Hold source for the line. Quiet Tone means no music on
hold for the selected line.
Possible values:Quiet Tone, External1~15, Internal (default)
F
IELD DESCRIPTION
