IP Telephone Programming
IP Telephone Installation and Network Connection Setup
8-22 Strata CIX Programming Vol.1 12/09
02 PDN Equipment
Number
Enter the PDN equipment number. This is the cabinet and slot number of the GIPx,
MIPU, LIPU/LIPS card (0000 means auto assignment).
Notes:
• IPT1020s must be installed on BIPU-M; cannot be installed on LIPU/LIPS,
MIPU or GIPx.
• SIP phones must be installed on LIPU/LIPS, MIPU or GIPx; cannot be
installed on BIPU-M
• IPT2000 series, IP5000-series, and IP Softphones can be installed on
LIPU/LIPS, MIPU, GIPx or BIPU-M (in BIPU-M the IP5000-series telephone
acts as an IPT2000-series telephone).
• MIPU and GIPU require R5.0 software or higher.
Cabinet numbers:
• CIX/CTX100: Select 01 for Base and Expansion cabinet.
• CIX200: Select 01 for Base and 02 for Expansion cabinet.
• CIX/CTX670: Select 01 for Base and 02~07 respectively for each
Expansion cabinet.
• CIX1200: Select 01 for Base and 02~12 respectively for each Expansion
cabinet.
Slot numbers:
• CIX/CTX100: Select 01~04 for Base slots and 05~08 for Expansion slots.
• CIX/CTX100: Virtual Slot for ACTU Relay = Cabinet 02, Slot 05.
• CIX200: Select 01~04 for either cabinet.
• CIX/CTX670: Select 01~08 for Base slots and 01~10 for Expansion slots.
• CIX1200:Select 01~08 for Base slots and 01~10 for Expansion slots.
• CTX28 and CIX40 assignments are hard coded and cannot be changed.
Virtual Slot for GCTU Relay = Cabinet 02, Slot 05.
01, 01 - 8 digital telephones on motherboard (CTX28, CIX40 R1HW and R2HW).
01, 02 - 3 CO lines on motherboard (CTX28, CIX40 R1HW), 4 CO lines (CIX40 R2HW)
01, 03 - no card (CTX28, CIX40 R1HW), GVPH (CIX40 R2HW)
01, 04 - 1 (Base) or 2 (GSTU) analog station ports (CTX28, CIX40 R1HW and R2HW)
01, 05 - GVMU (CTX28), GVPH (CIX40 R1HW), GIPx, MIPU or GCOCIH (CIX40
R2HW)
01, 06 - GIPx, MIPU16 or GCOCIH (CIX40 R1HW), no card (CTX28, CIX40 R2HW)
01, 07 - 8 digital telephones on GCDU (CTX28, CIX40 R1HW and R2HW).
01, 08 - 3 CO lines on GCDU (CTX28, CIX40 R1HW and R2HW).
03 LAN Interface
Number
Enter 1 for a GIPx, MIPU and LIPU, 2 for an LIPS
Possible values:1 (Default) or 2.
F
IELD DESCRIPTION
