Station
Assignment
Strata CIX Programming Vol.1 12/09 5-41
Station
Station Speed Dial Table View
Station Speed Dial Table View shows the entire set up for all speed dial numbers.
To access the System Speed Dial Table View
Select System > System Speed Dial Table View or from the program (516), click the Station Speed Dial
Table View button.
See Table Views on page 2-17 for table functionality.
PDN Table View
This screen shows the entire list of available PDNs.
To access the Station Speed PDN Table View
Select Station > PDN Table View.
Note See Table Views on page 2-17 for table functionality.
02 Number This is the dialable number stored in the speed dial bin.
Possible values:Up to 32 digits, 0~9, *, # and Pauses (default = no value)
To enter pauses enter Px, where x equals 0~9 (seconds), which is the length of
the pause, 0=10 seconds.
Note
• If the number being entered exceeds the 32 digits, the next speed dial
location will automatically be appended to create longer numbers.
• Also another speed dial bin can be nested within another bin for dialing
common numbers. If speed dial bin 100 has long distance access digits
1010321, these digits can be nested in to other speed dial bins by using
*100 as the first digits of the other bins. Example: Putting *10017145563425
into speed dial bin 150 would cause SD150 to dial the access digits plus the
number 10132117145563425.
• If you are programming from the telephone, the digits
*
and # have a special
meaning when programming speed dial numbers. The # digit indicates the
end of entry and
*
is an escape character. To dial the digits
*
or # as part of
the number; enter
**
or *#. To enter pauses enter *0~*9. The second digit
represents the number of seconds for the pause function.
03 Speed Dial Name Enter the LCD Name that displays on LCD dial directories.
Possible values:Up to 8 characters (default = no value)
Dialing Code Dial code that user accesses from the phone.
F
IELD DESCRIPTION
