IP Configuration
This program enables you to set up Network Communication Protocols.
Program Number(s): 916
Prerequisite Program: None
Reference: None
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press Hold.
At the PROG= prompt enter 916 and press Hold.
Notes
• The LCD only displays three of the twelve IP address digits at a time. Press the Speaker button to
view the remaining digits.
• The IP Address is the static IP address of the Strata CIX processor NIC/Ethernet connection only. The
PPP IP address for the Strata CIX processor modem is always 192.168.255.254 and cannot be
changed.
1. Press FB01 to view the current TCP/IP Address 1 (press FB02 to view the current Subnet Mask
Address 1, or press FB03 to view Default Gateway Address 1).
Press Hold.
2. Enter first IP Address Octet. To keep current setting go to Step 3.
3. Press Speaker button and enter second IP Address Octet. To keep current setting go to Step 4.
4. Press Speaker button and enter third IP Address Octet. To keep current setting go to Step 5.
5. Press Speaker button and enter fourth IP Address Octet. To keep current setting go to Step 6.
6. Press Hold.
7. Press FB02 to configure the remaining parameters.
8. Press Hold.
9. After all parameters are entered press Hold to submit the new settings.
10.You are automatically returned to the PROG= prompt.
11.Enter another program number to continue programming or press # # Hold again to exit programming
mode.
FB Name FB Summary Value
IP Address
01 Enter IP Address 1
192 = First IP Address Octet
168 = Second IP Address Octet
254 = Third IP Address Octet
253 = Fourth IP Address Octet
0~255
default = 192.168.254.253
Subnet Mask
02 Enter Subnet Mask Address 1 0~255
default = 255.255.255.0
Default Gateway
03 Enter Default Gateway 1 0~255
default = 0.0.0.0
