Strata CIX Programming Guidelines
Use Default Auto-programming to Start Up
1-4 Strata CIX Programming Vol.1 12/09
008 RDSU 4 standard
telephone and 4
digital Telephone
Standard Telephone, DKT2000 and
DKT3000/3200 without S-OCA, DP5xxx
(DKT3000 limitations:
DKT2000, 16 character LCD display on
DKT3000/3200, DKT3000/3200 LCD
Feature key does not function, DKT3014/
3214 large screen LCD does not display)
009 RCIU2+RCIS 4 or 8 Caller ID
interface
Caller ID interface for RCOU/RCOS and
RGLU analog CLID lines. Note: The
same Prog 100 code (009) is used for
RCIU2 with or without RCIS.
010 RMCU+RCMS 2 or 4 E911 analog
CAMA lines
CAMA lines Note: The same Program
100 code (009) used for RCIU2 with or
without RCIS.
011 REMU, BVPU 4 analog Tie lines, 4
VoIP circuits
Tie lines
012 RBSU 2 ISDN BRI (S/T)
circuits
TEI Type:
two TEIs
ISDN BRI CO lines
013 RBSU+RBSS 4 ISDN BRI (S/T)
circuits
TEI Type:
two TEIs
ISDN BRI CO lines
014 RPTU 16 or 24 ISDN PRI
channels
PCM Highway:
16 or 24
1
ISDN BRI CO lines
015 RBUU 2 ISDN BRI (U)
circuits
TEI Type:
two TEIs
ISDN BRI CO lines
016 RBUU+RBUS 4 ISDN BRI (U)
circuits
TEI Type:
two TEIs
ISDN BRI CO lines
1. If the slot next to an installed RDTU or RPTU is vacant, 24 lines or channels will be installed; If the slot next to an installed
RDTU or RPTU is occupied by another PCB, 16 lines or channels will be installed.
Table 1-4 Auto-Programming of Line Groups and Service Types
CO line type
OLG
Prog 306
ILG
Prog 304
CO Service Type
RCOU/RCOS and RGLU analog Loop
and Ground start
1 1 Direct In Termination (DIT) to the first PDN
(200 or 2000 – see Table 5)
RDDU analog DID 1 2 DID, wink – no default DID numbers
RDTU (T1) 1 3 DID – no default DID numbers
RMCU/RMCS analog CAMA 1 - Direct In Termination (DIT) to the first PDN
(200 or 2000 – see next table)
RBUU/RBUS and RBSU ISDN BRI - set
as CO side
2 4 DID – no default DID numbers
