Telephone Button Programming
900 Series Programs
13-10 Strata CIX Programming Vol.1 12/09
ISDN Trace Location
This program enables set up of ISDN protocol event trace collection conditions.
Program Number(s): 904
Prerequisite Program: None
Reference: None
Access Sequence: Login to programming mode from your telephone button pad:
Hold Q#Q#1Q2Q3Q.
At the PASSWORD= prompt enter your password and press
Hold.
At the PROG= prompt enter 904 and press Hold.
At the EQUIP= prompt enter the Shelf, Slot and Port numbers.
Notes
• Shelf, Slot and Circuit number is entered in “XXYYZZ” format where Shelf is a two digit value from
01~07 corresponding to the Strata CIX Cabinet number; slot is a two digit value from 01~10
corresponding to the Strata CIX Cabinet’s PCB slot number; circuit is a two digit value from 01~04
corresponding to the Strata CIX PCB Slot’s circuit number.
• Always use circuit 01 for RPTU.
1. Press FB01 to run a LLCI Trace. Press the Scroll or Page button to view Non, Brief, or Detailed
options. Enter 1~3 to determine Trace Level.
2. Press FB02 and
set CCL3 Trace Level. Press the Scroll or Page button to view Non, Brief, or Detailed
options. Enter 1~3 to determine Trace Level.
3. Press FB03 and
set L2L3 Trace Level. Press the Scroll or Page button to view Non, Brief, or Detailed
options. Enter 1~3 to determine Trace Level.
4. Press FB04 and set STATE Trace Level. Press the Scroll or Page button to view Non, Brief, or Detailed
options. Enter 1~3 to determine Trace Level.
5. Press FB05 and set ERRORS Trace Level. Press the Scroll or Page button to view Non, Brief, or
Detailed options. Enter 1~3 to determine Trace Level.
6. Press FB06 and set L2 Trace Level. Press the Scroll or Page button to view Non, Brief, or Detailed
options. Enter 1~3 to determine Trace Level.
7. Press Hold to execute.
8. Press # # Hold to return to the PROG= prompt.
9. Enter another program number to continue programming or press # # Hold again to exit programming
mode.
FB Name FB Summary Value LCD Prompt
LLCI
01 Level of collecting LLCI values. 1:None (no
information)
2:Brief
(important
information)
3:Detailled (all
information)
1:NON
2:BRIEF
3:DETAILED
Layer 3
02 Level of collecting Layer 3 messages.
Layer 2 and 3
03
Level of collecting Layer 2 and Layer 3
messages.
State Transitions
04 Level of collecting State Transitions.
Errors
05 Level of collecting errors.
Layer 2 States
06 Level of collecting Layer 2 States.
