Trunks
ISDN
6-38 Strata CIX Programming Vol.1 12/09
FIELD DESCRIPTION
00 PRI Card Equipment
Number
Enter the ISDN RPTU equipment number:
Enter data as XXYYZZ:
XX=cabinet 01~12
YY=slot 01~10
ZZ=PRI channel 01~24 (USA and Canada)
ZZ=E1/ETSI PRI channel 01~31 (other countries)
Example: If a line should be assigned to an RCOU in cabinet shelf 5, slot 2, circuit
3, enter 050203.
Cabinet numbers:
• CIX/CTX100: Select 01 for Base and Expansion cabinet.
• CIX200: Select 01 for Base and 02 for Expansion cabinet.
• CIX/CTX670: Select 01 for Base and 02~07 respectively for each
Expansion cabinet.
• CIX1200: Select 01 for Base and 02~12 respectively for each
Expansion cabinet.
Slot numbers:
• CIX/CTX100: Select 01~04 for Base slots and 05~08 for Expansion
slots.
• CIX/CTX100: Virtual Slot for ACTU Relay = Cabinet 02, Slot 05.
• CIX200: Select 01~04 for either cabinet.
• CIX/CTX670: Select 01~08 for Base slots and 01~10 for Expansion
slots.
• CXI1200:Select 01~08 for Base slots and 01~10 for Expansion slots.
01~31 B Channel ID Assign each ‘B’ channel as enabled or disabled for each channel on the interface.
The assignments must match exactly to the subscription from the PSTN.
Possible values:1 = Enable, 2 = Disable (default = 1)
